HMI IEX – A5W Compact
Compact HMI panel for treadmills The ideal solution for treadmill panels: A5W Compact works as an interface between the user and the treadmill, ensuring efficient control and compatibility with the standard drivers of the fitness market. Version with the standard display and compact keypad for optimal installation. Two modes of communication A5W Compact is used […]
User guide
HMI panel for treadmills
Compatible with other market standard VSDs
Standard display with compact keypad
Display for time, distance, calories, speed, and heart rate.
AW5 Compact was projected to be installed enclosed in treadmills. The panel displays: time, distance, calories, speed, and heart rate. It also allows the user to switch between normal, countdown, or preset training program modes.
This panel option has the standard A5W display in conjunction with a compact keypad, ideal for optimizing your installation in limited spaces without losing out on any of its functionality.
This HMI was constructed to operate in conjunction with Ageon’s driver, IEX70 PRO, though it is also compatible with the fitness market’s standard drivers that use frequency communication.
Power supply voltage: 5 Vcc (serial mode) and 12 Vcc (frequency mode);
Communication modes: Ageon serial and frequency;
Main board dimensions: 112 x 282 x 10,6 (mm);
Keypad dimensions: 50 x 107 x 9,6 (mm);
Cable length: 2 m.
Compact HMI panel for treadmills
The ideal solution for treadmill panels: A5W Compact works as an interface between the user and the treadmill, ensuring efficient control and compatibility with the standard drivers of the fitness market.
Version with the standard display and compact keypad for optimal installation.
Two modes of communication
A5W Compact is used at its full potential when in conjunction with Ageon’s drivers, but it’s also compatible with other models from other brands. The HMI provides great flexibility for your application with its two modes of communication (Ageon serial and frequency).
Compact display
The panel displays time, distance, calories, speed, and heart rate. Version with the standard display and compact keypad for optimal installation.
Sound alarms
It features a buzzer that emits audible signals to indicate board startup and the end of the exercise, improving user interaction.
Find more panel options for your treadmills
Discover other versions of the Ageon treadmill panel: IHM IEX A5W (standard version) and IHM IEX A5W Big Display (enlarged display and keypad).
