K116 Big Display
K116 Big Display is a temperature controller for refrigerated beverage displays or other applications that demand defrost control. Its main characteristics are the exclusive 30 mm display and the touch sensitive keys on the front panel. In addition to compressor control, it provides defrost management and control of fans and lighting.
User guide
Ideal for refrigerated beverage displays
Open door sensor
Built-in voltage monitor
Eco mode, a second setpoint to be easily selected
K116 Big Display is a temperature controller for refrigerated beverage displays or other applications that demand defrost control. Its main characteristics are the exclusive 30 mm display and the touch sensitive keys on the front panel. In addition to compressor control, it provides defrost management and control of fans and lighting.
K116 has a digital input for the open door sensor and allows for setting up to 4 setpoint presets with the Eco mode, for energy saving. The K116 Big Display controller features a built-in voltage monitor, protecting the equipment against mains voltage fluctuations.
Power supply voltage: (85 a 264) Vac /4 VA;
Relay output (max. 18 A total):
Ventilation: 10 A / 250 Vac (1/10 HP);
Defrost: 10 A / 250 Vac;
Lighting: 10 A / 250 Vac;
Cooling: 16 A / 250 VAC (1 HP);
Measurement range: (-50 to +100) °C;
Resolution:
0,1 ºC from (-9,9 to +9,9) ºC;
1,0 ºC from (-50 to -10)ºC and (+10 to +50) ºC;
Operating conditions: (0 to 50) °C and (10 to 90) %RH (noncondensing);
Dimensions:
Power supply module: (111,36 x 82,14 x 36,36) mm;
Display module: (116,53 x 55,95 x 30,33) mm;
Maximum Installation surface temperature: 50 °C;
NTC sensor: Ø6 mm / L=15 mm (sensor); Standard length 1,5 m (wiring).
Temperature control for refrigerated beverage displays
The K116 Big Display features a 30 mm display, as well as an integrated voltage monitor and defrost control, making it the ideal controller for beverage display applications.
Touch-sensitive keys
In addition to its sleek design, K116’s keys are touch sensitive.
Eco mode
With four pre-configured presets and an intelligent energy-saving mode, the temperature can be tailored to each application. The energy-saving mode is automatically activated after a period with the door closed, reducing energy consumption during low-usage periods. In addition, the user can manually activate the energy-saving mode at any time, ensuring full control of the system.
Defrost management
Prevent ice buildup and keep your refrigeration system running at peak efficiency with the K116 BD. It manages defrost via electric heaters or hot gas, ensuring optimal performance.
Ventilation management
With K116 Big Display your refrigeration is optimized by the precise ventilation control. Set up the ventilation functioning during defrosting, cooling cycle or with post-defrost delay for better performance.
Open door sensor
The digital input for the door sensor allows various actions to be configured, such as activating the energy-saving mode, triggering an alarm after a predefined time, and controlling ventilation and lighting, optimizing overall system performance.
Frequently asked questions
Yes, the K116 BD features a built-in voltage monitor, providing a reliable reference for equipment protection. It offers the accuracy required for compressor protection; however, a dedicated instrument is recommended for more precise measurements.
Yes, the K116 BD features an energy-saving mode that automatically shifts to a higher setpoint, reducing energy consumption during low-usage periods. The eco mode can also be automatically activated when the door is not opened for a configurable period.
To unlock the K116 BD display, press and hold the SET key and the up and down arrows simultaneously until the open padlock icon appears on the display.
Yes, the K116 BD allows different setpoints to be configured as presets, enabling multiple setpoints and energy-saving setpoints to be stored and applied for process optimization.
Yes, the K116 BD has an automatic wide-range power supply (85–264 VAC), ensuring compatibility with different mains voltages without requiring adjustments.
